Project history and design notes

These sections were in the repository README until it became a short landing page (#2322). They are kept here as they were: the module history, the original overview, architecture and roadmap summary, and the longer notes on tool calling, tracing, configuration loaders and the starter kit. The current user documentation is the guide and getting started; where a note below and a guide differ, the guide is right.

Overview

LLM4S provides a simple, robust, and scalable framework for building LLM applications in Scala. While most LLM work is done in Python, we believe that Scala offers a fundamentally better foundation for building reliable, maintainable AI-powered applications.

LLM4S Overview

Current Status

LLM4S is under active pre-1.0 development. The latest published release is v0.5.1; v0.5.0 was the first with the split module artifacts. Both target Scala 3.7.1 and JDK 21. Its APIs are usable today but are still being stabilized ahead of the 1.0 compatibility commitment.

The framework already provides multi-provider clients, agents and tool calling, RAG and vector stores, memory, guardrails, tracing and metrics, reliability wrappers, workspace isolation, MCP support, and image and speech APIs.

Since 0.5.0, llm4s ships as separate modules. RAG, knowledge graph, memory, MCP, shared media types, image, and speech have been carved out of llm4s-core into focused modules with smaller dependency footprints, and providers register through an SPI. Provider clients have moved into modules of their own - llm4s-ollama, llm4s-gemini, llm4s-anthropic, llm4s-openai, llm4s-openai-compatible (DeepSeek, Z.ai, OpenRouter, Mistral, Cohere and any OpenAI-compatible endpoint) and llm4s-voyage - and llm4s-core holds none. Langfuse tracing, the trace collector and store, and CostTracker are in llm4s-observability, and Prometheus metrics in llm4s-observability-prometheus, leaving llm4s-core with only the tracing and metrics contracts, console and no-op tracing, and no observability dependency. The agent runtime is in llm4s-agent and the built-in tools in llm4s-agent-tools, so llm4s-core is now a ~19k-line spine, and its API has been cleaned up ahead of the compatibility baseline, which is set at a pre-1.0 release once the designs are final (#1281). Upgrading from 0.4.x? Start with Upgrading from 0.4.1 to 0.5.0. See the 1.0 scope and migration guide for module maturity and upgrade details.

The path to 1.0 is focused on stable API boundaries, provider capability parity and contract tests, Java/Kotlin/Spring/Gradle interoperability, security hardening, deterministic CI, production observability and cost controls, runnable documentation, and maintained reference applications. See the roadmap for the full stabilization plan.

Why Scala for LLMs?

Type Safety: Catch errors at compile time, not in production.
Functional Programming: Immutable data and pure functions for predictable, maintainable systems.
JVM Ecosystem: Access to mature, production-grade libraries and tooling.
Concurrency: Advanced models for safe, efficient parallelism.
Performance: JVM speed with functional elegance.
Ecosystem Interoperability: Seamless integration with enterprise JVM systems and cloud-native tooling.

Choosing between JVM libraries? Comparing LLM4S sets LLM4S beside LangChain4j, Spring AI, Koog and Embabel, with a source and a date for every claim, and Migrating from LangChain4j maps its concepts to LLM4S.

Features

Multi-Provider Support: Connect to multiple LLM providers, including OpenAI, Anthropic, Azure OpenAI, Google Gemini, DeepSeek, Cohere, Mistral, OpenRouter, Requesty, Z.ai, and Ollama.
Execution Environments: Run LLM-driven operations in secure, containerized or non-containerized setups.
Error Handling: Robust mechanisms to catch, log, and recover from failures gracefully.
MCP Support: Model Context Protocol primitives for richer tool and context integration.
Agent Framework: Build single or multi-agent workflows with standardized interfaces.
Multimodal Generation: Support for text, image, voice, and other LLM modalities.
RAG (Retrieval-Augmented Generation): Built-in tools for search, embedding, retrieval workflows, and RAGAS evaluation with benchmarking harness.
Observability: Detailed trace logging, monitoring, and analytics for debugging and performance insights.
Raw Provider Exchange Logging: Persist request/response exchanges, including streaming responses for streaming-capable providers, to inspect raw provider payloads during development and debugging.

Architecture

        ┌───────────────────────────┐
        │    LLM4S API Layer        │
        └──────────┬────────────────┘
                   │
          Multi-Provider Connector
        (OpenAI | Anthropic | DeepSeek | ...)
                   │
         ┌─────────┴─────────┐
         │ Execution Manager │
         └─────────┬─────────┘
                   │
        ┌──────────┴──────────┐
        │   Agent Framework   │
        └──────────┬──────────┘
                   │
      ┌────────────┴────────────┐
      │  RAG Engine + Tooling   │
      └────────────┬────────────┘
                   │
     ┌─────────────┴─────────────┐
     │   Observability Layer     │
     └───────────────────────────┘

Roadmap

Our goal is to build a production-grade, type-safe AI application framework for Scala and the JVM, with multi-provider, multimodal, agentic, RAG, observability, and governance capabilities.

Detailed Roadmap

For the current roadmap, see the LLM4S Roadmap.

The roadmap covers:

Current Capability Map: What exists today and what still needs hardening
Production Pillars: Testing, API stability, provider parity, JVM adoption, security, performance, cost, documentation, and observability
2026 Stabilization Phases: The path from broad pre-1.0 functionality to a production-ready v1.0
Reference Applications: The maintained end-to-end apps needed before v1.0

High-Level Goals

Goal	Current state	Next focus
Single API access to multiple LLM providers	Implemented across many providers; a capability and tested-versions matrix generated from the code	Contract tests, parity for streaming/tools/structured output/timeouts/cost
Tooling for LLM applications	Tool calling, built-in tools, RAG, retrieval, evaluation, tracing, metrics, and reliability primitives exist	Stable APIs, security policies, runnable docs, and production examples
Agentic framework	Single-agent workflows, handoffs, memory, guardrails, streaming events, async tools, reasoning modes, and serialization exist	API freeze, replay/debugging, maintained reference apps
RAG and retrieval	Vector stores, hybrid search, reranking, permission-aware RAG, RAGAS-style evaluation, and benchmarking exist	Cost/latency tracking, deployment patterns, compile-tested golden paths
JVM ecosystem adoption	Scala-first path is the main supported API	Java facade, Kotlin coroutine API, Spring Boot starter, Maven/Gradle examples
Stable v1.0 platform	Pre-1.0, API stabilizing	MiMa or equivalent compatibility checks, threat model, benchmarks, docs cleanup, release gates

Tool Calling

Tool calling is a critical integration - designed to work seamlessly with multi-provider support and agent frameworks. We use ScalaMeta to auto-generate tool definitions, support dynamic mapping, and run in secure execution environments.

Tools can run:

In containerized sandboxes for isolation and safety.
In multi-modal pipelines where LLMs interact with text, images, and voice.
With observability hooks for trace analysis.

Tool Signature Generation

Using ScalaMeta to automatically generate tool definitions from Scala methods:

/** My tool does some funky things with a & b...
 * @param a The first thing
 * @param b The second thing
 */
def myTool(a: Int, b: String): ToolResponse = {
  // Implementation
}

ScalaMeta extracts method parameters, types, and documentation to generate OpenAI-compatible tool definitions.

Tool Call Mapping

Mapping LLM tool call requests to actual method invocations through:

Code generation
Reflection-based approaches
ScalaMeta-based parameter mapping

Secure Execution

Tools run in a protected Docker container environment to prevent accidental system damage or data leakage.

Comprehensive Tracing & Observability

Tracing isn’t just for debugging - it’s the backbone of understanding model behavior.LLM4S’s observability layer includes:

Detailed token usage reporting
Multi-backend trace output (console and none in llm4s-core; Langfuse from llm4s-observability, OpenTelemetry from llm4s-observability-otel)
Agent state visualization
Integration with monitoring dashboards

Tracing Modes

Configure tracing behavior using the TRACING_MODE environment variable. Console output (the default) and no tracing are built into llm4s-core; every other mode comes from a backend module you add as a dependency:

# Send traces to Langfuse - needs "org.llm4s" %% "llm4s-observability"
TRACING_MODE=langfuse
LANGFUSE_PUBLIC_KEY=pk-lf-your-key
LANGFUSE_SECRET_KEY=sk-lf-your-secret

# Print detailed traces to console with colors and token usage
TRACING_MODE=print

# Disable tracing completely
TRACING_MODE=none

Basic Usage

import org.llm4s.config.Llm4sConfig
import org.llm4s.trace.{ ConsoleTracing, Tracing }

// Build the tracer llm4s.tracing.mode selects; fall back to the console tracer
val tracer: Tracing = Llm4sConfig
  .tracing()
  .flatMap(Tracing.fromSettings)
  .fold(_ => new ConsoleTracing(), identity)

// Trace events, completions, and token usage
tracer.traceEvent("Starting LLM operation")
tracer.traceCompletion(completion, completion.model) // prefer the model reported by the API
tracer.traceTokenUsage(tokenUsage, completion.model, "chat-completion")
// An agent built withTracing(tracer) ends each run with a TraceEvent.AgentRunEnded

Usage using starter kit `llm4s.g8`

A carefully crafted starter kit to unlock the power of llm4s

Note: The LLM4S template has moved to its own repository for better maintainability and independent versioning.

The llm4s.g8 starter kit helps you quickly create AI-powered applications using llm4s. It is a starter kit for building AI-powered applications using llm4s with improved SDK usability and developer ergonomics. You can now spin up a fully working scala project with a single sbt command. The starter kit comes pre-configured with best practices, prompt execution examples, CI, formatting hooks, unit testing, documentation, and cross-platform support.

Template Repository: github.com/llm4s/llm4s.g8

Using sbt, do:

sbt new llm4s/llm4s.g8 \
--name=<your.project.name> \
--package=<your.organization> \
--version=<your.project.version> \
--llm4s_version=0.5.1 \
--scala_version=3.7.1 \
--munit_version=1.1.1 \
--directory=<your.project.name> \
--force

to create new project.

Since 0.5.0 llm4s-core ships no provider, so the generated build.sbt needs llm4s-core and at least one provider module at the same version. The template is being moved to 0.5.x (llm4s.g8#6), which adds llm4s-ollama and llm4s-openai itself; a template from before that lists llm4s-core only (and defaults to llm4s 0.4.0 if you leave out --llm4s_version), so add the provider you use, for example llm4s-openai at 0.5.1.

For more information about the template, including compatibility matrix and documentation, visit the template repository. Use the comprehensive documentation to get started with the project using starter kit.

Configuration: Unified Loaders

llm4s exposes a single configuration flow with sensible precedence:

Precedence: -D system properties > application.conf (if your app provides it) > reference.conf defaults.
Environment variables are read only where a ${?ENV} substitution binds them: in a module’s reference.conf (tracing, embeddings, tools, and each provider module’s vendor key under llm4s.credentials) or in your own application.conf. No .env reader is required, and nothing reads LLM_MODEL.

Preferred typed entry points (PureConfig-backed via Llm4sConfig):

Provider / model:
- Llm4sConfig.defaultProvider(): Result[ProviderConfig] – the typed config of the section llm4s.providers.provider names.
- Llm4sConfig.provider(name: String): Result[ProviderConfig] – the typed config of the section llm4s.providers.<name>.
- LLMConnect.getClient(config: ProviderConfig): Result[LLMClient] – builds a client from a typed config (with a given ModelRegistryService from Llm4sConfig.modelRegistryService()).
Tracing:
- Llm4sConfig.tracing(): Result[TracingSettings] – returns typed tracing settings.
- Tracing.fromSettings(settings: TracingSettings): Result[Tracing] – builds the tracer the mode selects; a missing backend is an error.
- Tracing.create(settings: TracingSettings): Tracing – the same, falling back to NoOpTracing with an error logged.
Embeddings:
- Llm4sConfig.embeddings(): Result[(String, EmbeddingProviderConfig)] – returns (provider, config) with validation.
- EmbeddingClient.from(provider: String, cfg: EmbeddingProviderConfig): Result[EmbeddingClient] – builds an embeddings client from typed config.

Recommended usage patterns:

Model name for display: Llm4sConfig.defaultProvider().map(_.model) or prefer completion.model from API responses.
Tracing:
- Llm4sConfig.tracing().flatMap(Tracing.fromSettings), or .map(Tracing.create) to fall back to no tracing.
Workspace (samples): WorkspaceConfigSupport.load() to get workspaceDir, imageName, hostPort.
Embeddings sample (samples): EmbeddingUiSettings.loadFromEnv, EmbeddingTargets.loadFromEnv, EmbeddingQuery.loadFromEnv (sample helpers backed by Llm4sConfig).

Config Keys → Typed Settings

Use these loaders to convert flat keys and HOCON paths into typed, validated settings used by the code:

LLM provider and model selection
- Keys: llm4s.providers.provider (the default section’s name) and llm4s.providers.<name>.{provider, model, apiKey, baseUrl, ...}. No environment variable is bound: bind your own with ${?VAR} in application.conf
- Type: ProviderConfig (with provider-specific subtypes)
- Loader: Llm4sConfig.defaultProvider() or Llm4sConfig.provider("name") + LLMConnect.getClient(...)

Tracing configuration

Keys: llm4s.tracing.mode TRACING_MODE (llm4s-core); llm4s.tracing.langfuse.* LANGFUSE_URL, LANGFUSE_PUBLIC_KEY, LANGFUSE_SECRET_KEY, LANGFUSE_ENV, LANGFUSE_RELEASE, LANGFUSE_VERSION (bound by llm4s-observability); llm4s.tracing.opentelemetry.* OTEL_SERVICE_NAME, OTEL_EXPORTER_OTLP_ENDPOINT (bound by llm4s-observability-otel)

Type: TracingSettings (the mode, plus the selected mode’s block as extras); LangfuseConfig via LangfuseConfigLoader.default()
Loader: Llm4sConfig.tracing() → then Tracing.fromSettings or Tracing.create

Workspace settings (samples)

Keys: llm4s.workspace.dir WORKSPACE_DIR, llm4s.workspace.image WORKSPACE_IMAGE, llm4s.workspace.port WORKSPACE_PORT

Type: WorkspaceSettings
Loader: WorkspaceConfigSupport.load()

Embeddings sample settings (samples only; bound under llm4s.samples.embeddings in the samples’ application.conf)
- Input paths: EMBEDDING_INPUT_PATHS or EMBEDDING_INPUT_PATH → EmbeddingSampleConfig.inputs() → EmbeddingTargets.fromInputs(...)
- Query: EMBEDDING_QUERY → EmbeddingSampleConfig.inputs() (or EmbeddingQuery.loadFromEnv()) → EmbeddingQuery
- Chunking: CHUNK_SIZE, CHUNK_OVERLAP, CHUNKING_ENABLED → EmbeddingSampleConfig.chunking()
- UI knobs: MAX_ROWS_PER_FILE, TOP_DIMS_PER_ROW, GLOBAL_TOPK, SHOW_GLOBAL_TOP, COLOR, TABLE_WIDTH → EmbeddingSampleConfig.ui() → EmbeddingUiSettings
- Non-text stubs: ENABLE_EXPERIMENTAL_STUBS, LLM4S_EMBEDDINGS_LOCAL_{IMAGE,AUDIO,VIDEO}_MODEL → EmbeddingSampleConfig.experimentalStubs(), .localModels()
Embeddings: provider configuration
- Key: EMBEDDING_MODEL / llm4s.embeddings.model as provider/model (or legacy EMBEDDING_PROVIDER / llm4s.embeddings.provider)
- Supported providers: openai (llm4s-openai), voyage (llm4s-voyage), ollama (llm4s-ollama); each from its module once published
- Type: (String, EmbeddingProviderConfig)
- Loader: Llm4sConfig.embeddings()
- Provider-specific keys:
  - OpenAI: OPENAI_EMBEDDING_BASE_URL, OPENAI_EMBEDDING_MODEL, and OPENAI_API_KEY - the same key OpenAI chat sections use
  - Voyage: VOYAGE_EMBEDDING_BASE_URL, VOYAGE_EMBEDDING_MODEL, VOYAGE_API_KEY
  - Ollama (local): OLLAMA_EMBEDDING_BASE_URL (default: http://localhost:11434), OLLAMA_EMBEDDING_MODEL
Provider API keys and endpoints
- Keys: apiKey and baseUrl inside each llm4s.providers.<name> section, plus the provider’s own keys - organization (OpenAI, Requesty, OpenRouter), endpoint and apiVersion (Azure), project and location (Vertex AI). A section without apiKey uses its vendor’s shared llm4s.credentials.<provider>.apiKey, which the provider module binds to OPENAI_API_KEY, ANTHROPIC_API_KEY and so on; a section’s own apiKey wins
- Type: concrete ProviderConfig (e.g., OpenAIConfig, AnthropicConfig, AzureConfig, OllamaConfig, GeminiConfig, DeepSeekConfig, CohereConfig)
- Loader: Llm4sConfig.defaultProvider() or Llm4sConfig.provider("name")

Tracing

Configure mode via llm4s.tracing.mode (default: console). Supported: console and noop (built into llm4s-core), langfuse (with llm4s-observability), opentelemetry (with llm4s-observability-otel), and any mode a TracingBackend on the classpath registers.
Override with env: TRACING_MODE=langfuse (or system property -Dllm4s.tracing.mode=langfuse).
Build tracers:
- Checked: Llm4sConfig.tracing().flatMap(Tracing.fromSettings) → Result[Tracing]
- Falling back to no tracing: Llm4sConfig.tracing().map(Tracing.create)
- Low-level: LangfuseConfigLoader.default().map(LangfuseTracing.from) (llm4s-observability)

Example (no application.conf required):

sbt -Dllm4s.providers.provider=openai-main -Dllm4s.providers.openai-main.provider=openai -Dllm4s.providers.openai-main.model=gpt-4o -Dllm4s.providers.openai-main.apiKey=sk-... "samples/runMain org.llm4s.samples.basic.BasicLLMCallingExample"

Or with an openai-main section (provider = "openai" and a model) in modules/samples/src/main/resources/application.local.conf and the samples’ LLM4S_PROVIDER binding:

export LLM4S_PROVIDER=openai-main
export OPENAI_API_KEY=sk-...
sbt "samples/runMain org.llm4s.samples.basic.BasicLLMCallingExample"
